Describe how machine learning and data analytics could have detected and/or prevented the APT you analyzed had the victim organization deployed these technologies at the time of the event. Be specific

Machine learning is a method of giving a computational device the ability to learn. It is different from traditional programming whereby the structure is logical, explicit, and conditional. Machine learning uses neural networks (among other techniques) and reinforcement learning to teach the computational device between what is correct or incorrect. One of the prerequisites of machine learning is data. Data is important because in order to teach the computational device how to learn, we need data to feed it.

For example, if we wanted to teach a computation device to identify pictures of dogs, we would need to submit pictures of dogs and pictures without dogs. The basics of a neural network can be found inside the system, and the neural network coupled with reinforced learning allows us to teach the computer. Essentially, the computation device will attempt to identify the pictures with dogs. If the system incorrectly identifies a picture, the human corrects the computational device. This is the reinforced learning aspect. It is akin to a teacher in grade school providing feedback on a math test. Once the system is trained, it has a high success rate of identifying pictures of dogs.

Let’s take a look at machine learning in the context of cybersecurity.

Machine learning is being applied to many fields across industry, one of which is cybersecurity. The key to success is data. In this field, there is plenty of data. Each device in the network can be configured to generate logs. Unfortunately, it’s virtually impossible for a human to review all the potential logs generated within a network. This is where machine learning comes in. For example, machine learning could be applied to the overall network when a breach has occured. A log is generated and a machine learning model (that has been trained) reacts by automatically responding to the breach. The speed at which the system responds is much faster than having a human in the loop.

Another example would be to automatically respond to sophisticated malware that is not being detected by traditional cybersecurity solutions. For example, when applying a heuristics-based model, the machine learning model would detect communication protocol behavior that is out of the norm for the network. At the very least, it would flag a human to review, and if desired, automatically prohibit the communication.

Machine Learning / NicoElNino /Essentials Collection /Getty Images

We experience machine learning every day. Spam filters, optical character recognition, and individualized content based on Internet surfing habits all use machine learning algorithms. Machine learning aims at "enabling computers to learn new behavior based on empirical data" (Tantawi, 2016) without being programmed by humans. Algorithms are designed to allow the computer to learn from past experience and use that to display new behavior. Machine learning is an important component of artificial intelligence (Tantawi, 2016).

Cognitive computing uses machine learning algorithms to analyze large amounts of data and produce results. Internet searches use cognitive computing to analyze the user's past search behaviors, combined with the current search request, to return results that, based on personal data and the application of patterns, are relevant and useful to the user.

Another example is the recommendations a user receives when on e-commerce sites, based on past searches, keywords, purchases of not only the user, but also other users that looked at the same product or used the same search terms. E-learning authors Mauro Coccoli, Paolo Maresca, and Lidia Stanganelli suggest that cognitive computing can enhance student performance and ease the instructor’s job of managing the class and learning materials (2016).

Machine learning, artificial intelligence, and cognitive computing are key players in learning analytics and predictive modeling. Machine learning has quickly become a key skill for developers to have as part of their toolbox.

Coccoli, M., Maresca, P., & Stanganelli, L. (2016). Cognitive computing in education. Journal of e-Learning and Knowledge Society, 12(2). ISSN 1826-6223. Retrieved from http://www.je-lks.org/ojs/index.php/Je-LKS_EN/article/view/1185/987

Tantawi, R. (2016). Machine learning. Salem Press Encyclopedia.

by Grant Ingersoll

Despite all the flashy headlines from Elon Musk and Stephen Hawking on the impending doom to be visited on us mere mortals by killer robots from the skies, machine learning and artificial intelligence are here to stay. More importantly, machine learning (ML) is quickly becoming a critical skill for developers to enhance their applications and their careers, better understand data, and to help users be more effective.

What is machine learning? It is the use of both historical and current data to make predictions, organize content, and learn patterns about data without being explicitly programmed to do so. This is typically done using statistical techniques that look for significant events like co-occurrences and anomalies in the data and then factoring in their likelihood into a model that is queried at a later time to provide a prediction for some new piece of data.

Common machine learning tasks include classification (applying labels to items), clustering (grouping items automatically), and topic detection. It is also commonly used in natural language processing. Machine learning is increasingly being used in a wide variety of use cases, including content recommendation, fraud detection, image analysis, and e-commerce. It is useful across many industries, and most popular programming languages have at least one open source library implementing common ML techniques.

Reflecting the broader push in software toward open source, there are now many vibrant machine learning projects available to experiment with as well as a plethora of books, articles, tutorials, and videos to get you up to speed. Let's look at a few projects leading the way in open source machine learning and a few primers on related ML terminology and techniques.

Beyond the project home pages and documentation, there are several excellent sources available to teach the core concepts behind machine learning. While there are hundreds (even thousands) of books and tutorials on ML, I've tried to focus on those targeted toward programmers and less on those that are more rigorous or focused too much on the math behind the scenes. While that stuff is important in the long run, it often impedes engineers in the getting-started phase from trying out real systems with real data.

• Programming Collective Intelligence: Building Smart Web 2.0 Applications by Toby Segaran is one of the best introductions to leveraging machine learning ideas for building web applications. Using examples in Python, Segaran lays out the concepts behind many common approaches for leveraging prior history for future benefit.

• Data Science From Scratch by Joel Grus. Another Python-based intro, Data Science walks you through core principles like linear algebra, statistics, and probability (but not too much!) before getting into the cornerstones of machine learning: regression, neural networks, and Naive Bayes.

• Andrew Ng's Coursera/Stanford University online class in machine learning. In many ways, Ng, first with his lectures on iTunes and now via Coursera, is the leading educator in machine learning. Be forewarned: this course requires commitment, but is well worth the time for a solid understanding of the topic.

• Data Science for Business: What You Need to Know About Data Mining and Data-Analytic Thinking by Foster Provost and Tom Fawcett. To quote the preface: "This is not a book about algorithms, nor is it a replacement for a book about algorithms. We deliberately avoided an algorithm-centered approach. We believe there is a relatively small set of fundamental concepts or principles that underlie techniques for extracting useful knowledge from data. These concepts serve as the foundation for many well-known algorithms of data mining."

• An Introduction to Machine Learning With Web Data by Hilary Mason. This video series by Mason and O'Reilly Media is an easy-to-understand, relatively short set of videos that introduce you to key topics in machine learning like clustering and classification.

While there are many great open-source machine learning projects out there, the following projects combine strong technical capabilities with good documentation and accessible communities for asking questions and troubleshooting.

Weka, from the University of Waikato in New Zealand, has long set the standard for open-source machine learning with a rich set of tools, lots of algorithms to try, and user interfaces for exploring data and results. It also has an excellent accompanying book that explains a lot of the ML concepts while showing examples using Weka. While it isn't necessarily up on the latest craze of deep learning and the like, it is a solid project to get started with in understanding the concepts.

Near and dear to my own heart as a co-founder of the project, Apache Mahout has retooled itself in the past year to focus on Apache Spark as well as on overhauling the way ML models are built while shipping implementations of commonly used ML algorithms. For those still using Hadoop MapReduce, Mahout continues to maintain implementations of key algorithms for classification, clustering, and recommendations using the MapReduce paradigm.

Built from day one for Apache Spark, MLLib is focused on delivering commonly used machine learning algorithms for clustering and classification in a scalable manner. By leveraging Spark, MLLib is able to take advantage of large-scale cluster optimizations for processing big data, which can be especially important in machine learning, since many of the algorithms used are iterative in nature and data-hungry.

Building on other solid Python libraries like NumPy and SciPy, scikit-learn brings many of the algorithms and tools covered in the above Java/Scala libraries to the Python stack. Add a nice set of tutorials, and you have a library poised to have you up and learning.

Capitalizing on the latest buzzword within the buzzword-laden field of ML, Deep Learning for Java brings to open source a strong set of algorithms designed to do single machine and distributed deep learning on Hadoop and Spark. It has a range of utilities for working with data and also has GPU (graphical processing unit) support.

What is deep learning? Increasingly used at places like Google, Facebook and Amazon, deep learning is a new, large-scale approach to neural networks designed to significantly reduce the amount of human intervention needed to train and maintain models while also providing significantly better results. DL4J, as it is called, also has a book by Adam Gibson and Josh Patterson.

As with any overview article, there simply isn't enough room to cover all the great projects in a space, so be sure to also check out H20, Vowpal Wabbit, and PredictionIO as well as the MLOSS archive of open-source machine learning libraries.

The real key to getting started in machine learning is to download sample data and the code from one of the projects above. Be prepared for lots of trial and error as you explore the different approaches. You will quickly find that, despite all the hype about artificial intelligence, building these applications still requires a good dose of human intelligence to get good results.

Getting Started With Open Source Machine Learning by Grant Ingersoll from Opensource.com is available under a Creative Commons Attribution-ShareAlike 4.0 International license. UMUC has modified this work and it is available under the original license.

by Jenna Burrell

This article considers the issue of opacity as a problem for socially consequential mechanisms of classfication and ranking, such as spam filters, credit card fraud detection, search engines, news trends, market segmentation and advertising, insurance or loan qualification, and credit scoring. These are just some examples of mechanisms of classification that the personal and trace data we generate is subject to every day in network-connected, advanced capitalist societies. These mechanisms of classification all frequently rely on computational algorithms and, lately, on machine learning algorithms to do this work.

Opacity seems to be at the very heart of new concerns about "algorithms" among legal scholars and social scientists. The algorithms in question operate on data. Using this data as input, they produce an output; specifically, a classification (i.e., whether to give an applicant a loan, or whether to tag an email as spam). They are opaque in the sense that if one is a recipient of the output of the algorithm (the classification decision), rarely does one have any concrete sense of how or why a particular classification has been arrived at from inputs.

Additionally, the inputs themselves may be entirely unknown or known only partially. The question naturally arises: What are the reasons for this state of not knowing? Is it because the algorithm is proprietary? Because it is complex or highly technical? Or are there, perhaps, other reasons?

By distinguishing forms of opacity that are often conflated in the emerging interdisciplinary scholarship on this topic, I seek to highlight the varied implications of algorithmic classification for longstanding matters of concern to sociologists, such as economic inequality and social mobility.

Three distinct forms of opacity include (1) opacity as intentional corporate or institutional self-protection and concealment and, along with it, the possibility for knowing deception; (2) opacity stemming from the current state of affairs where writing (and reading) code is a specialist skill; and (3) an opacity that stems from the mismatch between mathematical optimization in high-dimensionality characteristic of machine learning and the demands of human-scale reasoning and styles of semantic interpretation.

This third form of opacity (often conflated with the second form as part of the general sense that algorithms and code are very technical and complex) is the particular focus of this article. By examining in depth this form of opacity, I point out shortcomings in certain proposals for code or algorithm "audits" as a way to evaluate for discriminatory classification.

To examine this question of opacity, specifically toward the task of getting inside the algorithms themselves, I cite existing literature in computer science, known industry practices (as they are publicly presented), and do some testing and manipulation of code as a form of lightweight audit. Along the way, I relate these forms of opacity to technical and nontechnical solutions proposed to address the impenetrability of machine learning classification. Each form suggests distinct solutions for preventing harm.

The word algorithm has recently undergone a shift in public presentation, going from an obscure technical term used almost exclusively among computer scientists to one attached to a polarized discourse. The term appears increasingly in mainstream media outlets. For example, the professional body National Nurses United produced a radio spot  that starts with a voice that sarcastically declares, ''Algorithms are simple mathematical formulas that nobody understands,'' and concludes with a nurse swooping in to rescue a distressed patient from a disease diagnosis system which makes a series of comically wrong declarations about the patient's condition (see https://soundcloud.com/national-nurses-united/radio-ad-algorithms). The purpose of the public service announcement is to champion professional care (by nurses), in this case against error-prone automation.

By contrast, efforts at corporate branding of the term algorithm play up notions of algorithmic objectivity over biased human decision making (Sandvig, 2015). In this way, the connotations of the term are actively being shaped as part of advertising culture and corporate self-presentation, as well as challenged by a related counter-discourse tied to general concerns about automation, corporate accountability, and media monopolies (i.e., Tufekci, 2014).

While these new media narratives may be novel, it has long been the case that large organizations (including private sector firms and public institutions) have had internal procedures that were not fully understood by those who were subject to them. These procedures could fairly be described as "algorithms." What should we then make of these new uses of the term and the field of critique and analysis emerging along with it? Is this merely old wine in new bottles, or are there genuinely new and pressing issues related to patterns of algorithmic design as they are employed increasingly in real-world applications?

In addition to the polarization of a public discourse about algorithms, much of what is new in this domain are the more pervasive technologies and techniques of data collection; the more vast archives of personal data including purchasing activities, link clicks, and geospatial movement, an outcome of more universally adopted mobile devices, services, and applications; and the reality (in some parts of the world) of constant connectivity. But this does not necessarily have much to do with the algorithms that operate on the data. Often, it is about what composes the data and new concerns about privacy and the possibility (or troublingly, the impossibility) of opting out.

Other changes have to do with particular application areas and evolving proposals for a regulatory response. The shift of algorithmic automation into new areas of what were previously white-collar work is reflected in headlines such as "Will we need teachers or algorithms?" (Khosla, 2012) and into consequential processes of classification that were previously human-determined, such as credit evaluations in an effort to realize cost savings (as so often fuels shifts toward automation) (Straka, 2000).

In the domain of credit and lending, Fourcade and Healy point to a shift from prior practices of exclusionary lending to a select few to more generous credit offered to a broader spectrum of society–but offered to some on unfavorable, even usurious terms. This shift is made possible by "the emergence and expansion of methods of tracking and classifying consumer behavior" (Fourcade & Healy, 2013, p. 560). These methods are (in part) implemented as algorithms in computers. Here, the account seems to suggest an expansion of the territory of work claimed by particular algorithmic routines: that they are taking on a broader range of types of tasks at a scale that they were not previously.

In this emerging critique of "algorithms" carried out by scholars in law and in the social sciences, few have considered in much depth their mathematical design. Many of these critics instead take a broad sociotechnical approach looking at "algorithms in the wild." The algorithms in question are studied for the way they are situated within a corporation, under the pressure of profit and shareholder value, and as they are applied to particular real-world user populations (and the data these populations produce). Thus, something more than the algorithmic logic is being examined.

Such analyses are often particular to an implementation (such as Google's search engine) with its specific user base and uniquely accumulated history of problems and failures with resulting parameter setting and manual tweaking by programmers. Such an approach may not reveal important broader patterns or risks to be found in particular classes of algorithms.

In general, we cannot look at the code directly for many important algorithms of classification that are in widespread use. This opacity (at one level) exists because of proprietary concerns. They are closed in order to maintain competitive advantage and/or to keep a few steps ahead of adversaries. Adversaries could be other companies in the market or malicious attackers (relevant in many network security applications). However, it is possible to investigate the general computational designs that we know these algorithms use by drawing from educational materials.

To do this, I draw in part from classic illustrative examples of particular machine learning models, of the sort used in undergraduate education. In this case, I have specifically examined programming assignments for a Coursera course in machine learning. These examples offer hugely simplified versions of computational ideas scaled down to run on a student's personal computer so that they return output almost immediately. Such examples do not force a confrontation with many thorny, real-world application challenges. That said, the ways that opacity endures in spite of such simplification reveal something important and fundamental about the limits to overcoming it.

Machine learning algorithms do not encompass all of the algorithms of interest to scholars now studying what might be placed under the banner of the "politics of algorithms." However, they are interesting to consider specifically because they are typically applied to classification tasks and because they are used to make socially consequential predictions such as "How likely is this loan applicant to default?"

In the broader domain of algorithms implemented in various areas of concern (such as search engines or credit scoring), machine learning algorithms may play either a central or a peripheral role, and it is not always easy to tell which is the case. For example, a search engine request is algorithmically driven (except for the part—generally totally invisible to users—that may be done manually by human workers who do content moderation, cross-checking, ground truthing and correction) (Miller, 2014), but search engine algorithms are not, at their core, "machine learning" algorithms.

Search engines employ machine learning algorithms for particular purposes, such as detecting ads or blatant search ranking manipulation and prioritizing search results based on the user's location. (See the question and response on this Reddit AMA with Andrew Ng about why companies make their algorithmic techniques public–https://www.reddit.com/r/Machine Learning/comments/32ihpe/ama_andrew_ng_and_ adam_coates/cqbkmyb–and this Quora question and response about how machine learning contributes to the Google search engine—http://www.quora.com/Why-is-machine-learning-used-heavily-for-Googles-ad-ranking-and-less-for-their-search-ranking)

While not all tasks that machine learning is applied to are classification tasks, this is a key area of application and one where many sociological concerns arise. As Bowker and Star note in their account of classification and its consequences, "each category valorizes some point of view and silences another," and that there is a long history of lives "broken, twisted, and torqued by their encounters with classification systems," such as the race classification system of apartheid South Africa and the categorization of tuberculosis patients (Bowker & Star, 1999).

The claim that algorithms will classify more "objectively" (thus solving previous inadequacies or injustices in classification) cannot simply be taken at face value given the degree of human judgment still involved in designing the algorithms—choices which become built-in. This human work includes defining features, preclassifying training data, and adjusting thresholds and parameters.

Below, I define a typology starting first with the matter of "opacity" as a form of proprietary protection or as "corporate secrecy" (Pasquale, 2015). Secondly, I point to opacity in terms of the readability of code. Code writing is a necessary skill for the computational implementation of algorithms, and one that remains a specialist skill not found widely in the general public. Finally, arriving at the major point of this article, I contrast a third form of opacity centering on the mismatch between mathematical procedures of machine learning algorithms and human styles of semantic interpretation.

At the heart of this challenge is an opacity that relates to the specific techniques used in machine learning. Each of these forms of opacity may be tackled by different tools and approaches ranging from the legislative to the organizational or programmatic and to the technical. But importantly, the form (or forms) of opacity entailed in a particular algorithmic application must be identified in order to pursue a course of action that is likely to mitigate its problems.

One argument in the emerging literature on the "politics of algorithms" is that algorithmic opacity is a largely intentional form of self-protection by corporations intent on maintaining their trade secrets and competitive advantage. Yet this is not just about one search engine competing with another to keep its "secret sauce" under wraps. It is also the case that dominant platforms and applications, particularly those that use algorithms for ranking, recommending, trending, and filtering, attract those who want to "game" them as part of strategies for securing attention from the general public. The field of search engine optimization does just this.

An approach within machine learning called "adversarial learning" deals specifically with these sorts of evolving strategies. Network security applications of machine learning deal explicitly with spam, scams, and fraud and remain opaque in order to be effective. Sandvig notes that this game of cat and mouse makes it entirely unlikely that most algorithms will be (or necessarily should be) disclosed to the general public (Sandvig et al., 2014, p. 9). That said, an obvious alternative to proprietary and closed algorithms is open-source software. Successful business models have emerged out of the open-source movement. There are options even in "adversarial learning" such as the SpamAssassin spam filter for Apache.

On the other hand, Pasquale's more skeptical analysis proposes that the current extent of algorithmic opacity in many domains of application may not be justified and is instead a product of lax or lagging regulations. In his book The Black Box Society: The Secret Algorithms that Control Money and Information, he argues that a kind of adversarial situation is indeed in play, one where the adversary is regulation itself. "What if financiers keep their doings opaque on purpose, precisely to avoid or to confound regulation?"(Pasquale, 2015, p. 2). In reference to this, he defines opacity as "remediable incomprehensibility."

The opacity of algorithms, according to Pasquale, could be attributed to willful self-protection by corporations in the name of competitive advantage, but this could also be a cover for a new form of concealing sidestepped regulations, the manipulation of consumers, and/or patterns of discrimination.

For this type of opacity, one proposed response is to make code available for scrutiny, through regulatory means if necessary (Diakopoulos, 2013; Gandy, 2010; Pasquale, 2015). Underlying this particular explanation for algorithmic opacity is an assumption that if corporations were willing to expose the design of the algorithms they use, it would be possible to ascertain problems of consumer manipulation or regulatory violation by reading the code. Pasquale acknowledges that such measures could render algorithms ineffective, though he suggests that it may still be possible with the use of an independent, trusted auditor who can maintain secrecy while serving the public interest (Pasquale, 2015, p. 141). In the absence of access to the code, Sandvig et al. (2014) detail and compare several forms of algorithmic audit (carried out with or without corporate cooperation) as a possible response and a way of forcing the issue without requiring access to the code itself.

This second level of opacity stems from an acknowledgement that, at present, writing (and reading) code and the design of algorithms is a specialized skill. It remains inaccessible to most of the population. Courses in software engineering emphasize the writing of clean, elegant, and intelligible code. While code is implemented in particular programming languages, such as C or Python, and the syntax of these languages must be learned, they are in certain ways quite different from human languages. For one, they adhere strictly to logical rules and require precision in spelling and grammar in order to be read by the machine.

Good code does double duty. It must be interpretable by humans (the original programmer or someone adding to or maintaining the code) as well as by the computational device (Mateas & Montfort, 2005). Writing for the computational device demands a special exactness, formality, and completeness that communication via human languages does not. The art and craft of programming is partly about managing this mediating role and entails some well-known best practices like choosing sensible variable names, including "comments" (one-sided communication to human programmers omitted when the code is compiled for the machine), and choosing the simpler code formulation, all things being equal. (See also Ensmenger, 2003, on programming as craft and programmers as a profession.)

Recent calls for greater diversity in STEM fields and for general efforts toward developing computational thinking at all levels of education (Lee et al., 2011; Wing, 2006) are relevant. Diakopoulos (2013) likewise suggests ways that journalists might play a valuable role in reverse engineering algorithms to inform the general public, but notes that this poses a challenge of "human resource" development, one of developing code and computational literacy in journalists or others who wish to do this sort of examination. To address this form of opacity, widespread educational efforts would ideally make the public more knowledgeable about these mechanisms that affect their life opportunities and put people in a better position to directly evaluate and critique them.

Scholars have noted that algorithms (such as that underlying the Google search engine) are often component systems built by teams producing an opacity that programmers who are insiders to the algorithm must contend with as well (Sandvig, Hamilton, Karahalios, & Langbort, 2014; Seaver, 2014). A call for code "audits" (where this means reading the code) and the employment of auditors may underestimate what this would entail as far as the number of hours required to untangle the logic of the code within a complicated software system. This valid critique is nevertheless nonspecific about different classes of algorithms and their particular logics.

I further argue that there are certain challenges of scale and complexity that are distinctive to machine learning algorithms. These challenges relate not simply to the total number of lines or pages of code, the number of team members on the engineering team, or the multitude of interlinkages between modules or subroutines. These are challenges not just of reading and comprehending code, but being able to understand the algorithm in action, operating on data. Though a machine learning algorithm can be implemented simply in such a way that its logic is almost fully comprehensible, in practice such an instance is unlikely to be particularly useful. Machine learning models that prove useful (specifically, in terms of the "accuracy" of classification) possess a degree of unavoidable complexity.

Machine learning in particular is often described as suffering from the "curse of dimensionality" (Domingos, 2012). In a big data era, billions or trillions of data examples and thousands or tens of thousands of properties of the data (termed "features" in machine learning) may be analyzed. The internal decision logic of the algorithm is altered as it learns on training data. Handling a huge number of especially heterogeneous properties of data (i.e., not just words in spam email but also email header info) adds complexity to the code.

Machine learning techniques quickly face computational resource limits as they scale and may manage this using techniques written into the code (such as "principal component analysis"), which add to its opacity. While datasets may be extremely large but possible to comprehend and code may be written with clarity, the interplay between the two in the mechanism of the algorithm is what yields the complexity (and thus opacity). Better understanding this complexity (and the barriers to overcoming the opacity it effects) is the concern of the following examples.

Machine learning algorithms are used as powerful generalizers and predictors. Since the accuracy of these algorithms is known to improve with greater quantities of data to train on, the growing availability of such data in recent years has brought renewed interest to these algorithms.

A given machine learning algorithm generally includes two parallel operations, or two distinct algorithms: a classifier and a learner.

Classifiers take input (referred to as a set of "features") and produce an output (a "category"). For example, a classifier that does spam filtering takes a set of features (such as email header information, words in the body of the email, etc.) and produces one of two output categories (spam or not spam). A decision support system that does disease diagnosis may take input (clinical presentation/symptoms, blood test results) and produce a disease diagnosis as output (hypertension, heart disease, liver cancer, etc.).

However, machine learning algorithms called "learners" must first train on test data. (This refers to the subset of machine learning approaches called "supervised" learning which, for the sake of clarity of argument, is what is specifically considered here.) The result of this training is a matrix of weights that will then be used by the classifier to determine the classification for new input data. This training data could, for example, be emails that have been presorted and labeled as spam or not spam.

Machine learning encompasses a number of models that are implemented in code in different ways. Some popular machine learning models include neural networks, decision trees, naive Bayes, and logistic regression. The choice of model depends upon the domain (i.e., loan default prediction versus image recognition), its demonstrated accuracy in classification, and available computational resources, among other concerns. Models may also be combined into "model ensembles," an approach often used in machine learning competitions that seek to maximize accuracy in classification. Two applications of machine learning using separate models will be considered below.

The first model and application of machine learning I wish to consider is a "neural network" applied to an image recognition task. Because this is an image recognition task, it lends itself to an attempt to see the weights output by the training algorithm. The classic example for teaching neural networks to computer science undergraduates is handwriting recognition. (Giving some sense of perhaps how little the algorithms themselves have changed, this is the same example used to teach neural networks in the course I took as an undergraduate in 2001 as well as in the Coursera course I completed in 2013.)

To simplify the computational task for educational purposes, the code is implemented to recognize handwritten digits only (the numbers 0 through 9). To further simplify the task, these digits are drawn within the boundaries of a space-constrained box. In the top figure below, you can see some of the fuzziness and ambiguity of the data that is to be classified. If you take a single handwritten number in an 8 by 8 pixel square, each pixel (and a grayscale value associated with it) becomes an input (or "feature") to the classifier, which ultimately outputs what number it recognizes (in the case of the second figure, it should be the number 6).

A set of examples of handwritten numbers that a machine learning algorithm (a learner) and, in this case, a neural network could be trained on.

A handwritten number in an 8 x 8 pixel square.

In the design of a neural network, a set of input nodes connects to a second set of nodes called the hidden layer (like interlinked neurons in the brain) and then to an output layer (see the next figure). Each input node is connected to a hidden layer node and each node in the hidden layer is connected to an output in the design of the neural network in that figure. A value or weight is associated with each of these connecting lines.

The optimal values for the matrix of weights are what the learning algorithm learns. What is optimal is defined by the set of weights that produce the most accurate possible classification of inputs (the individual pixels and their intensity ranging from white to black in an 8 by 8 matrix) to outputs (the handwritten numbers these pixels represent).

Graphical depiction of a neural network.

Because this is an image recognition task, we can actually visualize the optimized weights coming into the hidden layer node. In this way, we can see the way a neural network breaks down the problem of recognizing a handwritten number (see the following figures).

Left, the hidden layer: The black areas in each box are the areas (strokes or other patterns) that a particular hidden layer node cues in on in a handwritten digit. Right: This shows the result of the same learning algorithm being run a second time with the same training data. The reason they are not identical is because of the random initialization step that defines the set of weights initially to very small random numbers.

The figure at above left illustrates the hidden layer in a neural network. If you look at one of the 25 boxes, you can see which part of a handwritten number it cues in on. Each box represents a single node in the hidden layer, and each pixel within the box illustrates the value of the weight coming from one input layer node into that particular hidden layer node. In sum, each box shows the set of weights for a simplified neural network with only one hidden layer.

The regions in the box that are black are the specific pixels in which the node in question is most sensitive. The top left box, for example, shows a hidden layer node that cues in on darkened pixels in the lower left part of the quadrant and a little bit in the middle. A combination of the calculations coming out of these hidden layer nodes yields a classification of the inputs to a number from zero to nine.

What is notable is that the neural network doesn't, for example, break down handwritten digit recognition into subtasks that are readily intelligible to humans, such as identifying a horizontal bar, a closed oval shape, a diagonal line, etc. This outcome, the apparent nonpattern in these weights, arises from the very notion of computational "learning."

Machine learning is applied to the sorts of problems for which encoding an explicit logic of decision making functions very poorly. In his machine learning Coursera course, Andrew Ng describes this as the domain of "[applications] we cannot program 'by hand.'" (Coursera, “Welcome,” n.d.). The "hand" is implied to be a human one. To program "by hand" (in the context of classification decisions) would also entail outlining explicitly a logic of decision making, specifically about which category to place a piece of data into.

This "rationalistic" approach known as symbolic AI (Olazaran, 1996) was once dominant. It is sometimes referred to, with more than a bit of nostalgia, as Good Old Fashioned AI (GOFAI) (Winograd, 2006), and it entailed the symbolic representation of knowledge in a way that is strictly formalized. However, this approach failed to live up to its early promise and underperformed on many tasks, leading to an AI "winter" when interest and funding waned (Grudin, 2006).

As noted, the craft of code writing (by humans) is two-sided communication, for fellow human programmers on the one hand and for the computer processor on the other. Where an algorithm does the "programming" (i.e., optimally calculates its weights), then it logically follows that being intelligible to humans (part of the art of writing code) is no longer a concern—at least, not to the nonhuman programmer.

The primary purpose of this first example is to give a quick, visual sense of how the machine "thinks." The figure at upper left above should appear unintuitive, random, and disorganized. However, handwriting recognition specifically is not a conscious reasoning task in humans, either. Humans recognize visual elements in an immediate and subconscious way (thus there is certainly a kind of opacity in the human process of character recognition as well).

Such an example may not seem to provide much insight into broader real-world questions about discrimination in classification. However, a case where automated classification in Google Photos labeled a set of photos of African-American people as "gorillas" suggests otherwise (Brogan, 2005). To further the argument, my next example, spam filtering, looks at the automation of a task that calls upon a more conscious form of human reasoning. As a matter relating to core communication capabilities of the internet, I show how spam filtering is of relevance to questions of classificatory discrimination.

Spam has no fixed and indisputable definition (Brunton, 2013). It is generally understood to be unwelcome emails, especially those sent in bulk, but this is, in part, a designation by network administrators concerned particularly with overtaxing network resources. Spam filtering is, for this reason among others, a better application domain for thinking about machine learning-based classification as socially consequential.

Messages that are categorized as spam are messages that do not get through to their intended recipients. Consequently, this example relates more directly to ongoing conversations about the politics of search, ranking, and filtering content. Where a legitimate message is categorized as spam (a false positive), this is a message that has, in effect, been unwittingly censored.

One question is whether the design of spam filters could make certain individuals more susceptible to having their legitimate messages diverted to spam folders. For example, does being located in a hotbed of internet fraud or spam activity, say West Africa (Nigeria or Ghana) or Eastern Europe, create a tendency for one's messages to be mislabeled as spam?

In Ng's Coursera course, support vector machines (SVMs) are the machine learning model used to implement spam filtering. SVMs are another type of machine learning model, like neural networks, and either model could be used for spam filtering. The simplified version used in the Coursera course does not use the "kernel trick," a computational technique characteristic of SVMs, so it is essentially a form of linear regression; in technical terms it uses a "linear kernel."

As an additional simplification, the programming exercise relies solely on the contents of the email to train a spam classifier—that is, the words contained in the message alone, and no email header information. These words are analyzed by the learner algorithm to determine a set of weights. These weights measure the degree to which a given word is associated with spam vs. "ham" (nonspam) emails. Such an approach is described as a "bag of words." There is no posited semiotic relationship between the words, and there's no meaning in the messages extracted, nor is there an attempt in the algorithm at narrative analysis.

I offer a lightweight audit of the algorithm and an examination of the weights produced for each word and how we might make sense of them. In particular, I focus on a type of spam email, the Nigerian 419 scam, a genre with which I have deep familiarity (Burrell, 2012). The 419 scam raises an interesting concern as far as network access and spam false positives. In particular, are place names, particularly Nigeria, a trigger leading to a greater likelihood of categorizing as spam?

In fact, after running the training algorithm on an (admittedly) very dated public corpus (2002), a list of place names can be produced with their associated "weights." These weights are in a range from −1 (highly associated with nonspam e‑mails) to 1 (highly associated with spam emails). Reassuringly perhaps for the general population of Nigerian email users, the weight associated with the word "Nigeria" contained within an email is -0.001861. This means that Nigeria is essentially a neutral term. Looking at the totality of spam, this makes a certain amount of sense. On the balance of it, the majority of spam does not originate in or make mention of Nigeria. Presumably, the number of totally legitimate emails that mention Nigeria would further dilute an association between the country and spam email.

The words that are in fact most associated with spam (note, that the words have been destemmed so that groups of words such as guarantee, guarantees, and guaranteed can be handled as equivalent terms) are the following:

• our (0.500810)

• click (0.464474)

• remov (0.417698)

• guarante (0.384834)

• visit (0.369730)

• basenumb* (0.345389)

• dollar (0.323674)

• price (0.268065)

• will (0.264766)

• most (0.261475)

• pleas (0.259571)

(*All numbers in the text are replaced with 'basenumb' in the preprocessing of the email contents.)

In many cases, these are terms we would expect to cut across genres of spam. They seem to suggest generic appeals, pleading and promises ("guarantee"); the authority of a collective ("our"); and concrete and quantified gain or benefit (especially monetary).

Consider below a specific example of spam in the Nigerian 419 style recently caught in my Gmail account spam filter, which is indeed categorized as spam by the simplified SVM spam filter:

My Dearest,

Greetings to you my Dear Beloved, I am Mrs Alice Walton, a citizen of United State. I bring to you a proposal worth $ 1,000,000,000.00 which I intend to use for CHARITY but I am so scared because it is hard to find a trust worthy human on earth...

In reading this email, I notice the formality of language and words like "dearest" and "beloved." The mention of being a "citizen," offering "charity" and looking for someone "trustworthy" strike a note of suspicion. None of these words, however, are cued in on by the SVM spam filter. Rather, it is the mention of money and the words "please" and "contact" that are the most heavily weighted terms found in this particular email. In fact, after removing the mention of money and the "please" from the email and running it through the classifier algorithm again, it is no longer classified as spam.

Now for comparison, consider this email from a friend and research collaborator, an email that has many of the same markers of the scam email genre (formality, religiosity, expressions of gratitude, etc.) but is not a scam email:

Dear prof. Thank you for continually restoring hope and bringing live back to me when all hopes seem to be lost. With tears and profound gratitude I say thank you. ...Am able to get a big generator, air-conditioned, a used professional Panasonic 3ccd video camera and still have about 150 dollars in my account for taking care of my health. …I pray you continually prosper. Much regards and Bye.

The spam classifier accurately categorizes this email as not spam, again based purely on the words it contains (with no knowledge about the author's preexisting relationship with the sender).

Nonetheless, when run through the classifier algorithm, there are certain trigger words present in the email (including "want" and "will") and, most incriminatingly, there is mention of money. The ranking of words by weight seems to offer a kind of lever for sense-making for the interpreting human mind, but the overall classification, even in this highly simplified example, cannot easily be ascertained by a brief skimming of the words and their associated weights in a particular email. It is the aggregate of all of the weights of the words found in the email matched to a dictionary of 1,899 of the most frequently used words. Minute differences and key words (i.e., "visit" or "will") that cannot easily be made sense of as part of spam strategies of social engineering, and persuasion may tip the balance of the classification.

Humans likely recognize and evaluate spam according to genre: the phishing scam, the Nigerian 419 email, the Viagra sales pitch. By contrast, the "bag of words" approach breaks down texts into atomistic collections of units, words whose ordering is irrelevant. The algorithm surfaces very general terms characteristic of spam emails, often terms that are (in isolation) mundane and banal. My semantic analysis attempted to reconcile the statistical patterns the algorithm surfaces with a meaning that relates to the implicit strategy of the text as a whole, but this is decidedly not how the machine "thinks."

The example provided of classifying Nigerian 419 style spam emails gives some insights into the strengths and shortcomings of a code audit. Finding ways to reveal something of the internal logic of an algorithm can address concerns about lack of "fairness" and discriminatory effects, sometimes with reassuring evidence of the algorithm's objectivity, as in the case of the neutral weighting of the word "Nigeria." On the other hand, probing further into the why of a particular classification decision yielded suggestive evidence that seemed sufficient as an explanation, but this imposed a process of human interpretive reasoning on a mathematical process of statistical optimization. In other words, machine thinking was resolved to human interpretation. Yet ambiguities remained, such as the weighting of innocuous words as indicators for spam. This raises doubts about whether an explanation produced in this way to satisfy the why question was necessarily a particularly correct one.

Computer scientists term this opacity issue a problem of "interpretability." One approach to building more interpretable classifiers is to implement a component facing the end user to provide not only the classification outcome but also expose some of the logic of this classification. A real-world implementation of this in the domain of spam filtering is found in Google's Gmail spam folder. If you select a spam message in this folder, a yellow alert box with the query "Why is this message in Spam?" above the text of the email itself provides one reason why it has been placed in this folder. (A list of these explanations: https://support.google.com/mail/answer/1366858?hl=en&expand=5) Messages include "it contains content that's typically used in spam messages" (perhaps a reference to a "bag of words" approach) and "many people marked similar messages as phishing scams, so this might contain unsafe content."

And yet, explanations that bring forward a human-manageable list of key criteria (i.e., the 10 most heavily weighted/spammy words present in an email or a single sentence description) provide an understanding that is at best incomplete (one computer scientist likewise reminds us that "the whole reason we turn to machine learning rather than handcrafted decision rules is that for many problems, simple, easily understood decision theory is insufficient" [Lipton, 2015]) and at worst false reassurance.

Further complicating the attempts to draw a direct line between "weighted" inputs and classification outcomes is the mathematical manipulation that happens in between. Unlike the examples of handwriting recognition and spam filtering presented above, it is often the case that the relationship between a feature and a dimension in the model is not one-to-one. Ways of manipulating dimensionality (through principal component analysis or the kernel trick in SVMs, to give two examples) are often employed to manage computational constraints or to improve accuracy.

The continuing expansion of computational power has produced certain optimization strategies that exaggerate this particular problem of opacity as the complexity of scale even further. With greater computational resources, and many terabytes of data to mine (now often collected opportunistically from the digital traces of users' activities), the number of possible features to include in a classifier rapidly grows way beyond what can be easily grasped by a reasoning human.

In an article on the folk knowledge of applying machine learning, Domingos (2012) notes that "intuition fails at high-dimensions." In other words, reasoning about, debugging, or improving the algorithm becomes more difficult with more qualities or characteristics provided as inputs, each subtly and imperceptibly shifting the resulting classification.

For handling this fundamental opacity, there are various proposed approaches. One approach, perhaps surprisingly, is to avoid using machine learning algorithms in certain critical domains of application. One social scientist doing field work among researchers developing a self-driving car found that these researchers avoid using machine learning entirely because "you don't know what it learns." The innumerable situations not represented in the training set lead to unpredictable and possibly potentially life-threatening consequences (Both, 2014).

In personal conversations with me, researchers at Yahoo! and Fair Isaacs Corporation (the source for FICO scores) have also described an avoidance of machine learning algorithms for this reason. In the credit market this isn't just a preference, but enforced through the Fair Credit Reporting Act, which requires that reasons be provided to consumers for denied credit. "Alternative credit scoring" or "consumer scoring" agencies, however, do freely use ML models and are not (yet) subject to these regulations (for details see Cathy O'Neill's "Doing Data Science").

There are also ways of simplifying machine learning models such as "feature extraction," an approach that analyses what features actually matter to the classification outcome, removing all other features from the model. Some solutions perhaps wisely abandon answering the why question and devise metrics that can, in other ways, evaluate discrimination (i.e., Datta, Tschantz, & Datta, 2015). For example, in "Fairness Through Awareness," a discriminatory effect in classification algorithms can be detected without extracting the how and why of particular classification decisions (Dwork et al., 2011). In some ways this extends the approach of the external audit proposed by Sandvig et al. (2014) and by Diakopoulos (2013) using sophisticated algorithmic implementations.

"There may be something in the end impenetrable about algorithms" (Gillespie, 2012).

The goal of this article was to look more deeply into machine learning algorithms and the nature of their opacity, relating this to sociological interests in classification and discrimination. This is part of an ongoing reorientation of the scholarship on "digital inequality" which has frequently focused on the distribution of computational resources and skills (Hargittai, 2008) but not, until recently, on the question of how people may be subject to computational classification, privacy invasions, or other surveillance in ways that are unequal across the general population and could be in violation of existing regulatory protections (Barocas & Selbst, 2014; Eubanks, 2012; Fourcade & Healy, 2013).

Legal critiques of algorithmic opacity often focus on the capacity for intentional secrecy and lead to calls for regulations to enforce transparency. Pasquale (2015) argues for the use of auditors who have access to the code and can assure that classifications are nondiscriminatory. Another approach is to educate a broader slice of society in code writing and computational skills to lessen the problem of a homogenous and elite class of technical people making consequential decisions that cannot be easily assessed by nonmembers. However, the opacity of machine learning algorithms is challenging at a more fundamental level. When a computer learns and consequently builds its own representation of a classification decision, it does so without regard for human comprehension. Machine optimizations based on training data do not naturally accord with human semantic explanations.

The examples of handwriting recognition and spam filtering helped to illustrate how the workings of machine learning algorithms can escape full understanding and interpretation by humans, even for those with specialized training or even for computer scientists.

Ultimately, partnerships between legal scholars, social scientists, domain experts, and computer scientists may chip away at these challenging questions of fairness in classification in light of the barrier of opacity. Additionally, user populations and the general public can give voice to exclusions and forms of experienced discrimination (algorithmic or otherwise) that the domain experts may lack insight into, For example, many different groups have experienced problems with Facebook's "real names" policy and its mechanism for reporting and verification (Kayyali, 2015). Alleviating problems of black-boxed classification will not be accomplished by a single tool or process, but some combination of regulations or audits (of the code itself and, more importantly, of the algorithms functioning), the use of alternatives that are more transparent (i.e., open source), education of the general public as well as the sensitization of those bestowed with the power to write such consequential code. The particular combination of approaches will depend upon what a given application space requires.

Barocas, S., & and Selbst, A. (2014). Big data's disparate impact. California Law Review, 104(3), 671–732.

Both, G. (2014). What drives research in self-driving cars? (Part 2: Surprisingly not machine learning) [Blog post]. http://blog.castac.org/2014/04/what-drives-research-in-self-driving-cars-part-2-surprisingly-not-machine-learning

Bowker, G. C. & Star, S. L. (1999). Sorting things out: Classification and its consequences. The MIT Press.

Brogan, J. (2015, June 30). Google scrambles after software IDs photo of two black people as “gorillas.” https://slate.com/technology/2015/06/google-s-image-recognition-software-returns-some-surprisingly-racist-results.html

Brunton, F. (2013). Spam. The MIT Press.

Burrell, J. (2012). Invisible users: Youth in the internet cafes of urban Ghana. The MIT Press.

Coursera. (Producer).. (n.d.). Welcome. In Machine Learning [video]. https://www.coursera.org/lecture/machine-learning/welcome-RKFpn

Datta, A., Tschantz, M. C., & Datta, A. (2015). Automated experiments on ad privacy settings: A tale of opacity, choice, and discrimination. In Proceedings on Privacy Enhancing Technologies, June 30–July 2, 2015, Philadelphia, PA.

Diakopoulos, N. (2013). Algorithmic accountability reporting: On the investigation of black boxes. Tow Center for Digital Journalism, Columbia University, New York.

Domingos, P. (2012). A few useful things to know about machine learning. Communications of the ACM, 55(10), 78.

Dwork, C., Hardt, M., Pitassi, T., Reingold, O., & Zemel, R. (2012). Fairness through awareness. In Proceedings of the 3rd Innovations in Theoretical Computer Science Conference, January 8–10, Cambridge, MA, pp. 214–226.

Ensmenger, N. L. (2003). Letting the "computer boys" take over: Technology and the politics of organizational transformation. International Review of Social History, 48(S11), 153–180.

Eubanks, V. (2012). Digital dead end: Fighting for social justice in the information age. The MIT Press.

Fourcade, M., & Healy, K. (2013). Accounting, organizations and society classification situations: Life-chances in the neoliberal era. Accounting, Organizations and Society, 38(8), 559–572.

Gandy, O. H. (2010). Engaging rational discrimination: Exploring reasons for placing regulatory constraints on decision support systcites. Ethics and Information Technology, 12(1), 29–42.

Gillespie, T. (2012). The relevance of algorithms. In T. Gillespie, P. Boczkowski, & K. Foot (Eds.), Media technologies: Essays on communication, materiality, and society. The MIT Press.

Grudin, J. (2006). Turing maturing: The separation of artificial intelligence and human-computer interaction. Interactions, 13(5), 54–57.

Hargittai, E. (2008). The digital reproduction of inequality. In D. Gursky (Ed.), Social stratification, pp. 936–944. Westview Press.

Kayyala, D. (2015, February 15). Facebook’s name policy strikes again, this time at Native Americans. https://www.eff.org/deeplinks/2015/02/facebooks-name-policy-strikes-again-time-native-americans

Khosla, V. (2012). Will we need teachers or algorithms?  https://techcrunch.com/2012/01/15/teachers-or-algorithms/

Lee, I., Martin, F., Denner, J. Coulter, B., Allan, W., Erickson, J., Malyn-Smith, J., & Werner, L. (2011). Computational thinking for youth in practice. ACM Inroads, 2(1), 32–37.

Lipton, Z. (2015). The myth of model interpretability. http://www.kdnuggets.com/2015/04/model-interpret-ability-neural-networks-deep-learning.html

Mateas, M., & Montfort, N. (2005). A box, darkly: Obfuscation, weird languages, and code aesthetics. In Proceedings of the 6th Annual Digital Arts and Culture Conference, December 1–3, Copenhagen, Denmark.

Miller, G. (2014, December 8). The huge, unseen operation behind the accuracy of Google Maps. https://www.wired.com/2014/12/google-maps-ground-truth/

Olazaran, M. (1996). A sociological study of the official history of the perceptrons controversy. Social Studies of Science, 26(3), 611–659.

Pasquale, F. (2015). The black box society: The secret algorithms that control money and information. Harvard University Press.

Sandvig, C. (2014). Seeing the sort: The aesthetic and industrial defense of "the algorithm." Journal of the New Media Caucus, 10(3), 1–21.

Sandvig, C., Hamilton, K., Karahalios, K., & Langbort, C. (2014). Auditing algorithms: Research methods for detecting discrimination on internet platforms. In Annual Meeting of the International Communication Association, Seattle, WA, pp. 1–23.

Seaver, N. (2014). Knowing algorithms. In Media in Transition 8, Cambridge, MA.

Straka, J. W. (2000). A shift in the mortgage landscape: The 1990s move to automated credit evaluations. Journal of Housing Research, 11(2), 207–232.

Tufekci, Z. (2014). The year we get creeped out by the algorithms. http://www.niciteanlab.org/2014/12/the-year-we-get-creeped-out-by-algorithms

Wing, J. M. (2006). Computational thinking. Communications of the ACM, 49(3), 33–35.

Winograd, T (2006). Shifting viewpoints: Artificial intelligence and human-computer interaction. Artificial Intelligence, 170(18), 1256–1258.
